Add a hardware volume control dial to Picade Max USB Audio.
Picade Max Encoder is a small board with a digital rotary encoder conveniently pre-attached. Connect it up to the 'Encoder' port on Picade Max USB Audio and adjust the volume of your homebrew arcade machine (or alternate cool DIY build), with no soldering required ✨ The encoder is also a button, so you can click it to mute/unmute.
It comes with the same snazzy black aluminium dial that we use in our Picade Max kit, and a 200mm cable for plugging it in. If you need a longer cable, they're available here.
Kit includes
- Picade Max Encoder board, with EC11 digital rotary encoder
- Black aluminium dial
- JST-SH to JST-SH cable (200mm)
Picade Max USB Audio board is sold separately.
Notes
- This is not an I2C device! We've used a 4 pin JST-SH connector for convenience but it's not compatible with Qw/ST / Qwiic / STEMMA QT.
- Dimensions:
- Board measures 18 x 38 mm (L x W)
- Total assembled height: 22mm (approx)
- The mounting holes are M2.5, inset 3mm from each edge (AKA 32x12 hole pattern).
